Thrust Ball Bearings

Thrust ball bearings are manufactured as single direction or double direction thrust ball bearings. They are designed to accommodate axial loads only and must not be subjected to any radial load.

In addition to the bearings presented in this section, AGA supplies thrust ball bearings for special application requirements.


PDF
Down		 Inquiry Bearing
Model		 Principal Dimensions Basic Load
Ratings		 Speed
Ratings		 Related Parts
d D H H1 Cr C0r Reference
Speed		 Limiting
Speed		 Housing
Washer
[mm] [mm] [mm] [mm] (kN) (kN) [r/min] [r/min]
BA 3 3 8 3.5 —— 0.806 0.72 26000 36000 ——
BA 4 4 10 4 —— 0.761 0.72 22000 30000 ——
BA 5 5 12 4 —— 0.852 0.965 20000 28000 ——
BA 6 6 14 5 —— 1.78 1.92 17000 24000 ——
BA 7 7 17 6 —— 2.51 2.9 14000 19000 ——
BA 8 8 19 7 —— 3.19 3.8 12000 17000 ——
BA 9 9 20 7 —— 3.12 3.8 12000 16000 ——
51100 10 24 9 —— 8.71 12.2 9500 13000 ——
51200 10 26 11 —— 12.7 18.6 8000 11000 ——
51101 12 26 9 —— 10.4 16.6 9000 13000 ——
51201 12 28 11 —— 13.3 20.8 8000 11000 ——
53201 12 28 11.4 13 13.3 20.8 8000 11000 U 201
51102 15 28 9 —— 10.6 18.3 8500 12000 ——
51202 15 32 12 —— 15.9 25 7000 10000 ——
53202 15 32 13.3 15 15.9 25 7000 10000 U 202
51103 17 30 9 —— 11.4 21.2 8500 12000 ——
51203 17 35 12 —— 16.3 27 6700 9500 ——
53203 17 35 13.2 15 16.3 27 6700 9500 U 203
51104 20 35 10 —— 15.1 29 7500 10000 ——
51204 20 40 14 —— 21.2 37.5 6000 8000 ——
